Why create a PlanStudio Digital Twin for your existing building?

Written by
Helen Hall
Published on
May 24, 2023

The collapse of Champlain Towers South in Surfside, Florida on 24 June 2021, is a tragic event that won’t be forgotten. Fire fighters searched through the ruins for almost a month to locate the 98th deceased occupant, terrible outcome and completely avoidable.

Investigations into how and why this occurred will be ongoing, but it won’t change the horror and loss experienced on that day for the families, community and first responders.

As with other building collapses, the data available on the building is critical to the rescue mission. Where are people trapped? What hazards in the building could make the rescue mission more challenging? What infrastructure may be damaged and pose a threat? This is something that Locatrix’s clients and partners are well aware of in planning for such events.

In Australia we are fortunate to have very strict building codes and processes – but as we have seen with the Opal Towers in Homebush in Sydney, they are not foolproof. Building plans change from design to construction due to many reasons such as the search for more feasible outcomes in construction materials, forced changes in construction materials which are often necessary due to high demand and supply issues or better options in materials coming onto the market. There are many reasons why variations happen throughout a building process and they are sometimes very difficult to anticipate, mediate and manage.

A building certifier will oversee these changes during construction and will approve them based on the information they are aware of at the time, but something time has always taught us is that times change and so do circumstances.

Asbestos was once considered the miracle material. It was used heavily in construction due a number of benefits that were hard to ignore: materials were cheap, durable, lightweight and could offer scientific benefits that many buildings lacked at the time. It wasn’t until 1990 that the use of asbestos in Australia ceased due to the discovery that exposure to asbestos fibres and dust can result in asbestos diseases. Just like Asbestos, there is the recent cladding issue where at the time, was considered a great solution for making a building more attractive, to shelter it from wind and weather and to assist with insulation measures. It didn’t take long for the discovery to be made that it was highly flammable and could spread a fire rapidly to higher levels of a Highrise and externally building, compromising the compartmentation provided in the building’s structure and evacuation methods.

As with anything realized with hindsight, how does one go back and remediate these issues? How do the authorities keep a record of where these materials are still used in order to roll out a program to rectify? How do we save buildings from an unsafe building, as it is burning or collapsing?

There are no fast answers to these questions but there is a way to know more – and to share more of this information with the first responders that need to know it most of all.

Many new buildings are now benefiting from the innovative technology a Digital Twin provides. This is where the process of construction is modeled digitally prior to construction or where proposed changes to materials/methods can be tested out virtually before the heavy investment of construction. This is great for all the new buildings that can afford this technology but what do we do about the old buildings that have inherited the problems like asbestos or friable cladding?

In the instance of a building collapse, how can we know that rooms are under each level in order to locate occupants in order to rescue them? How do we know what rooms to evacuate first and out of what exit with there is a structural issue with the level above?

Locatrix has a quick and easy solution with PlanStudio. With over 70,000,000 sqm of floor plans captured since 2019, PlanStudio is a proven fast and efficient way of mapping your building and creating digital floor plans that a building manager can add layering to in order to include important information such as where hazardous materials are stored or where a structural issue has been detected. By providing a “thin twin” that one can build on in order to make a full “digital twin” PlanStudio can be used to collect necessary information to effectively manage any risks of an aging building.


With this data collected and safety stored to ISO27001 security standards, it is only shared with whom the building owner wants to share it with – and on top of that list should be Emergency Services. We call it the ESP (Emergency Services Platform).

Saving Lives and maintaining building safety is easier to do when you have the right tool to do it. PlanStudio is an amazing application which every building manager can use. Why create your building's Digital Twin?  Because PlanStudio makes it easy to do.
